ソフトウェア・クラウドツール BIM/CIM i-Construction
Sanei

基本情報

屋内小間番号
07-52
所在地
〒730-0014 広島県広島市中区上幟町3-26 広島メイプルビル4F
電話番号
082-228-2221
ホームページアドレス
出展社へのお問い合わせ

出展製品・サービス

STRAXcube

製品・サービス説明

STRAXcube is a 3D civil engineering design system for roads that combines 2D and 3D design. It links 3D models with design studies and 2D drawings.
The internal data is constructed in 3D. When changes are made to plane alignment, vertical alignment, width configuration, or existing topography, the 3D model, resulting drawings, and quantity calculations are instantly updated. This frees the user from the current BIM/CIM design process where 2D and 3D are separated.

Main Functions of STRAXcube
Accurately calculate 3D road surfaces, slopes, and retaining walls for various alignments, including main lines, ramps, and side roads.
It also includes 3D design for all types of intersections, such as cross, T-shape, H-shape, roundabout, and installation on a single screen.
Additionally, it covers retaining wall calculations for complex structures, including wings, shoulders, and
slopes, as well as 3D design of waterways and catch basins on plan view, and drainage calculations by determining the catchment area.
Finally, it mentions the linkage of design drawings, quantity calculations, and 3D models.


REDcube "Pavement inspection"

製品・サービス説明

Pavement inspections are carried out using the Mobile Mapping System.
Inspections include pavement cracks, ruts, flatness, IRI and evaluation maps using AI.


Snow Removal Support System

製品・サービス説明

This is an automated system for snow removal equipment and a guidance system that displays geographical objects, such as curbs and manholes, during snow removal operations. It also provides warnings of approaching objects.

In recent years, municipalities in areas with heavy snowfalls have faced the urgent task of ensuring a stable snow removal system for the future due to the aging of skilled operators and a lack of personnel. Our objective is not only to compensate for the shortage of experienced operators but also to attain automatic control of snow removal equipment while ensuring safety even with only one operator.
To address this issue, we combine high-precision 3D maps created from point clouds and camera information from MMS, drones, etc., with highly accurate positioning systems such as single-frequency RTK-GNSS. We are also striving to enhance safety by automating snow removal equipment.
